Noyafa NF-308 Multipurpose LCD Display Network Telephone Cable Tester Tracker Line Finder Wire Tester Cable Locator


Directly hunt 5E, 6E, telephone wire, coaxial cable, USB cable and other cables.
Check wiring error in 5E, 6E, coaxial cable, such as open circuit, short circuit, jumper wire, reverse connection.
Locate the wiring or connection error.
Measure cable length and determine the distance of open circuit and short circuit.
Automatically time-delay shut off.

Support backlight display function.
Single board computer software watchdog design and reliable operation.
Verify RJ45 and BNC conductors.

Brand Name : Noyafa
Model Number : NF-308
Material: Plastic
Port : RJ45, RJ11, BNC, USB
Test length : RJ45
Wiremap Type: RJ45, BNC Cable
Tracking Type : RJ45, RJ11, BNC ,USB and Metal Cable
Other Function : LED Flash and Loud Speaker
Power : 9V Alkaline battery(Not Included)
Warranty : 1 year

Transmitter specifications:
Indicator: LCD 53x25 mm, with back light
Tone frequency: 225 Hz
Max. distance of transmission:  2 km
Max. distance of cable map: 1 km
Max. working current: Less than 70mA
Tone mode: 2 Tone adjustable
Compatible connectors: RJ11,RJ45,Coaxial, USB
Max. signal voltage: 15Vp-p
Function selection: 3 position buttons & 1 power switch
Function and faults LCD display: LCD display (wiremap, Tone, short, , No adapter, Low  battery)
Cable map indication: LCD (#1-#8)
Shielded indication: LCD ( #9)
Voltage protection: AC 60V/DC 42V
Battery Type: DC9.0V (NEDA 1604/6F22 DC9V x 1pcs)(Not Included)
Dimension(LxWxD): 185x80x32mm

Receiver specifications:
Frequency: 225kHz
The Max. working current: Less than 70mA
Earjack: 1
LED illumination: 2
Battery Type: DC9.0V (NEDA 1604/6F22 DC9V) x1pcs)(Not Included)
Dimension(LxWxD): 218x46x29mm

Remote unit specifications:
Compatible connectors: RJ11, RJ45, Coaxial, USB
Dimension(LxWxD): 107x30x24mm

Package included:
1 x Tester
1 x Receiver
1 x Remote Adapter
1 x Earphone
1 x RJ11 Adaptor Cable
1 x RJ45 Adaptor Cable
1 x Alligator Clip Adaptor
1 x User Manual
1 x Warranty card
1 x Color Packing Box

1.Don\'t connected high voltage lines to avoid burning out the machine.
2.Put into the right place to avoid hurting others,because of the sharp part.
3.Connected the cable to the right port.
4.Read the user manual before use it.
